Beitian BN-220 GPS Module for FPV Racing

Beitian BN-220 GPS Module for FPV Racing

৳ 2,250



  • Brand: Beitian BE-220
  • Cold Start : 26s
  • Warm start : 25s
  • Hot start : 1s
  • Altitude : 50,000m Max
  • Velocity : 515m/s Max
  • input : DC 3.0V-5.5V
  • Current : Capture 50mA/5.0V
  • Operating temp : -40 °C ~ +85°C
  • Support : GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
  • Accuracy: : 2M (Horizontal) CEP 2D RMS SBAS Enable
  • Velocity : 0.1m/sec 95% (SA off)
  • Update Rate : 4800bps to 921600bps, Default 9600bps
  • Data Protocol : NMEA-0183, Default NMEA-0183
  • Single GNSS : 1Hz-18Hz
  • TX LED:blue.The data output, TX LED flashing
  • PPS LED:red.PPS LED not bright when GPS not fixed,flashing when fixed
  • Dimension : 22mm*20mm*6mm
  • Weight : 5.3g



In stock
